Name: Mobile 5 Multi Parameter Patient Monitor 80VA Power Audible And Visual Alarm
Brand: STATEMED
Price: 1 USD

Brand Name : STATEMED

Model Number : STT15-MPM42

Certification : CE

Place of Origin : CHINA

MOQ : 1 SET

Price : competitive

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets per month

Delivery Time : 10 working days

Packaging Details : carton, wooden case

Supply power : AC 220V±10% 50/60Hz±2%

Power : 80VA

Display mode : LCD display

Alarm mode : Audible and visual

Network connection : Can be expanded

Product Name : Clinic patient monitor

Contact Now

High Quality Medical Mobile Multi Parameter Patient Monitor with CE

Battery

Battery type	rechargeable li-ion battery 12V/2300mAH
Recharge time	≥4 hour
Use time	≥120 minute

Work Environment

ECG

Lead	Standard Three leads		R,L,N, lead mode :Ⅰ,Ⅱ,Ⅲ
	Standard Five leads		R,L,F,N,C, Lead mode :Ⅰ,Ⅱ,Ⅲ,aVR,aVL,aVF,V；
Sensitivity			2.5mm/mV,5mm/mV,10mm/mV,20mm/mV,erro≤±3%
Scan speed			12.5,25,50mm/s three level,erro ≤±10%
Inner voice			<30μV_P-P
input impedance			≥5MΩ
input loop current			≤0.1μA
endure electrode polarizing voltage			±300mV
Frequency property			diagnosis mode 0.05～130HZ monitoring mode 0.5～40HZ operating 1～20HZ
CMRR			Diagnosis mode ≥90dB Monitoring mode ≥100dB Operating mode ≥100dB
HR measurement range			Adult 15～300bpm Neonate /pediatrics 15～350bpm
HR accuracy			±2%
alarm range			0～301bpm, upper and lower limit can be adjusted continuously
alarm indicator			Audial and visual alarm
protection			Isolated immunity voltage 4000V, Immunity of electronic surgical Anti-defibrillation
protection and recovery for defibrillation effect			In the monitor and the surgical model ,ECG waveforms recovery to baseline in 5S.
Electrode polarization recovery time after the fibrillation			In the monitor and the surgical mode ,ECG waveforms recovered to baseline in 10S.
measurement mode			Diagnosis mode,monitoring mode,operation mode
pace marker pulse detection and suppressing		width	±2mV～±700mV
		broadband	0.1ms～2ms
		risetime	10μs～100μs
ECG signal input range			-8.0mV～+8.0mV
HR sensitivity			>200μV
